VAC Motorsports Race Seat Installation Kit, Mini R5x

Side:

Add Seat Slider & Hardware? [VAC-SLIDER] $99.95 additional charge

Price: $379.95

Quantity:

Add To Cart

SKU: VAC-RSIK-Mini-B

Sharing Discount has been applied

Tell A Friend

Description

VAC BMW Race Seat Installation Kits are by far the easiest, most popular and best way to mount race seats into your Mini, period.

Our acclaimed Race Seat Installation Kit is a nearly 100% universal application that will work with almost any side mount sport or racing seat and allow a properly centered and comfortable driving position.

These have been used to install all popular brands including: Sparco, Cobra, Status, MOMO, Bride, Recaro, Sabelt, Kirkey ect. some Racetechs may require slight modification to the side mounts but the majority do not. The bottom line: this kit will work with nearly any side mount seat available.

Our kits are available in combination of silver and/or black, and include both VAC Floor Mount Adapters, VAC Superior Side Mount Brackets, and all necessary hardware.

VAC Floor Mount Adapters

Available for: Cooper/ Cooper S 02-on (R50 & R53 based) chassis, as well as 07-on (R56 based) [May fit others, not test fit yet]
CAD designed, real world tested
Allows the lowest install of any seat brackets available
Allow easy install of any racing / sports seat
Adapts side mount seat brackets to the factory floor mounting points
Lightweight design
Fully compatible with sliders (works with side or bottom mount seats)
Kit comes complete with all needed hardware
100% bolt-in install
Made from strong 6061-T6 Billet Aluminum

VAC Superior Side Mount Brackets
are specifically contoured to help you get the best fitments in the tight floor pan of modern vehicles like BMWs. By allowing your seat the greatest amount of side-to-side lateral movement and height flexibility, this movement assures not only a comfortable- personalized fitment, but also the ability to fit your seat of choice without being offset from the steering wheel like the seat companies side mounts. By utilizing VAC side mounts, you can locate your seat without jamming into the B-pillar or hitting the tranny tunnel/center console; seats that would normally be impossible to fit without heavy modification fit fast and easily. Skip the seat companies side mounts and get the right fit the first time!

Wider slots in our Side-mount mounting flange to accommodate differing seat widths and seating preferences.
Narrow Profile Design Side-mounts to allow seats to be moved to your Liking and closer to tunnel for better fit and weight distribution.
Lightweight yet extremely rigid aluminum construction Vs stamped steel.
Aluminum will not rust or corrode, even if the powder coat is removed
Perfectly Compliment our World-Class VAC Floor Mount Adapters.

Please Specify: Left (USA driver’s side) or Right side

Customer Reviews

There are currently no reviews of this product.

New

Installation Instructions

Please use these instructions and guidelines to aid in the installation of your new product.

Your kit should include the following:

(2) Floor Mount Adapter “bars” - Inner and Outer

(4) Bolts- M8 x 1.25 x 25mm Hex Head

(4) Washers- 8mm ID, 24mm OD

(2) Side Mount Brackets

1. Please check that all components listed above have arrived in your box and are ready to be installed. Look closely, as some components may have shifted, or become mixed in with packing materials. If you are missing any components, please contact us right away.

2. For all BMW applications: If one Floor Mount Adapter bar is wider than the other, the widest bracket always mounts closest to the outside of the car.

3. Begin to bolt our adapters to the floor first, keep them loose enough to move around a bit.

4. If you have maintained your original interior, carpet and insulation can compress down without any issues whatsoever. If you are not comfortable doing this, you can use a washer under each mounting location to space it up slightly.

5. Seat placement is a personal preference. If you’re aiming for best high performance ergonomics, a good outline to work within is one that keeps the driver fairly upright and comfortable. One that the pedals can be fully depressed without over extending the knee joint, and one that enables the driver to turn the wheel close to 180 degrees without taking their hands off the wheel (usually your elbows will be at, or close to, right-angles).

6. For the E36 and E46 cars, the wide Floor Mount Adapter mounts closest to the door.

7. Once you have found your location, you are ready to bolt your side brackets to the seat and set the seat down onto the floor mount adapters, again keep everything a little loose. If you have VAC side mount brackets (like in our Race Seat Installation Kit), skip to step #9.

8. At this step, if you have run out of adjustment room (if your side mount brackets are too wide for your floor pan), may we recommend our VAC Universal Side Mount brackets, made specially narrow for tight installs on most modern floor pans. If you have adequate clearance and room for comfortable placement of your seat, proceed on.

9. Eye up the closest holes to use on your seat and clearly mark them on the seat and bracket (we recommend using some masking tape for this job). Sometimes, depending on the manufacturer and type of your seat, an elongation of the holes in the side bracket may be required.

10. Once everything is assembled loosely and your seat is positioned where you want to use it, start to tighten the floor mount adapter bolts and then the side mount to floor mount adapter bolts in that order. You can then tighten your seat to the side mount brackets.

11. You are finished!   Test your seat mounts and seats for play, you should have none. Make sure everything is tightened properly and securely, and that you have left no tools in the vehicle.

Enjoy your sport seats and be safe!
