There are a multitude of reasons one might need new lug bolts.
Whatever yours are, our high quality Premium Lug Bolts are available in both standard and extended lengths.
Our Bolts feature...
- A high luster finish that's clean and simple
- Resistance to corrosion
- Won't Chip or peal like black coated bolts
- Grade 10.9 construction
- M12 x 1.5mm thread, with compact 17mm hex head
- Fitment for most BMWs (does not fit X5, X6 or E65 7-series, which use M14 hardware)
**Bolts Priced individually**
For example: Stock E36 Bolt 26mm UL
M12 bolts, under-head length available in:
- 26mm (OE E36)
- 28mm +2
- 31mm +5
- 35mm +9
- 39mm +13
- 43mm +17
Q: What size bolt do I need?
A: Measure the Under-head Length (UL) of your original bolt: from the tip of the bolt to just under the conical portion of the top.
- If you are replacing a standard bolt, simply order the same size.
- If you are using spacers, calculate the additional length you are adding example: 25mm Under-head Length + 20mm spacer = 45mm.
- Insure that you have at least 12mm engagement into the wheel hub.
Due to the nature of variations between wheels and spacer, VAC can-not offer recommended lengths. The lengths you require should be verified by measurement.
VAC Tech Note
The use of any anti-seize compound, spray lubricant like WD-40®, grease, or any other oil/lubricant on the threads is dangerous and will cause an inaccurate torque reading when installing your lug bolts or studs.
WE STRESS the use of a torque wrench whenever installing wheels! Over tightening can cause a fatigue or yield of the shaft leaving a damaged, dangerous bolt. You may clean, and chase threads, however use anti-seize at your own risk.
Use of a torque wrench is a must, BMW suggest 88 ft. lbs on the M12 bolts.
Did you know?: If you plan on serious driving and cannot remember the last time you replaced your lugs... it might be time...
Lugs are considered a consumable item and do stretch, fatigue and wear out over time!
